RS2014L Century Belt Drive and Blower Motor, Split Phase (1/6 HP, 48 Frame, 1725 RPM)

Model Number: RS2014L, HP: 1/6, RPM: 1725, Volts: 115, Frame: 48, Enclosure: Open D.P., Type: Split Phase Resilient Base Motor,

Applications

Belt Drive Fans and Blowers, HVAC

Features

Class B Ins. (Class A see notes); Reversible; Continuous Duty; Sleeve & Ball Bearing; Energy Efficient $ (see notes); 60 HZ; Open and Encloseds

Tech Specs.
Brand	A.O. Smith
Model Number	RS2014L
HP	1/6
RPM	1725
Volts	115
Full Load Amps	4
Service Factor	1.35
Frame	48
Enclosure	Open D.P.
Apx. Wt. (lb)	10
Phase	Split Phase
Protector	None
Type	Split Phase Resilient Base Motor
Aprox "C"	8.9
Dim "AG"	7.3
Motor Mount	Resilient Base
	RS2014L

Support Documents (pdf)
Product Literature
