U.S. SEAL MFG.

PS-2203 U.S. SEAL MFG. Pump Seal (1.25" Shaft Size, O-Ring Seat, SS/P66/EPR)

PS-2203 U.S. SEAL MFG. Pump Seal (1.25" Shaft Size, O-Ring Seat, SS/P66/EPR)

[COUNT] shoppers are looking at this right now

PS-2203

$123.14 USD
$215.50 USD $123.14 USD
Sale Sold out
Shipping calculated at checkout.

U.S. SEAL MFG. PS-2203, 1.25" Shaft Size, Replacement Pump Seal and Pump Shaft Seal.

Elastomer bellows seal, non-clogging, single coil spring. The drive band's notch design eliminates overstressing of the bellows. Common in rotary and turbine pumps, compressors, mixers, blenders and chillers.

  • Manufacturer: U.S. Seal Manufacturing
  • Part Number: PS-2203
  • Shaft Size: 1.250" (1-1/4")
  • Rotary Head Type: US Seal Type C (John Crane Type 21)
  • Rotary Head Material: SS/P66/EPR
  • Rotary Head Dimensions: 1.937" OD, 1.062" Operating Height
  • Stationary Seat Type: O-Ring Seat (US Seal Type 3)
  • Stationary Seat Material: Stainless/EPR
  • Stationary Seat Dimensions: 1.875" Bore, 0.437" Thick
  • Maximum Temperature: 300F (149C)
  • Maximum Pressure: to 150 psi (10.3 Bar)
  • Seal Faces: P66 Metal-Filled Carbon vs. Stainless
  • Elastomers: EPR
  • Questions about this product? Contact our team!
  • This item is direct shipped from the manufacturer. Lead times will vary. Contact for availability.
  • All images shown on our website are for illustration purpose only and may not be an exact representation of the product. Actual products may vary from the images shown.
