WEG

PCJ120H WEG Motor, Pool and Spa Pump (2 HP, M56J FRAME, 230 V, SINGLE PHASE, ODP , 3490 FULL LOAD SPEED)

PCJ120H WEG Motor, Pool and Spa Pump (2 HP, M56J FRAME, 230 V, SINGLE PHASE, ODP , 3490 FULL LOAD SPEED)

SKU:PCJ120H

Regular price $354.18 USD
Regular price Sale price $354.18 USD
Sale Sold out
Shipping calculated at checkout.

Don't see the price?

Certain manufacturers require online sellers to display a price that meets or surpasses the manufacturer's set MAP (Minimum Advertised Price). As we are providing a price lower than the MAP, please Add the Product to Your Cart for pricing details or Request a Quote.

WEG Motor PCJ120H, 2 HP , 3490 FULL LOAD SPEED, M56J FRAME, 230 V , SINGLE PHASE, 60 Hz , ODP , Pool and Spa Pump Motor
Applications
Pool & Spa
Features
Pool & Spa Pump Motor, Single Phase, Rolled Steel, Standard Efficiency, ODP

Tech Specs

Brand
WEG Motors
Model Number
PCJ120H
OUTPUT HP
2 HP
FULL LOAD SPEED
3490
FRAME
M56J
VOLTAGE
230 V
PHASE
SINGLE
FREQUENCY
60 Hz
ENCLOSURE
ODP
APPROXIMATE WEIGHT (lb)
34
FEET
NO
TERMINAL BOX
LEFT
FLANGE
FC-149
RATED CURRENT
9.20 A
LOCKED ROTOR CURRENT IL IN
7
LOCKED ROTOR CURRENT
64.4 A
LOCKED ROTOR TORQUE
2.2
BREAKDOWN TORQUE
2.7
EFFICIENCY 50
66
EFFICIENCY 75
73
EFFICIENCY 100
78.3
POWER FACTOR 50
0.78
POWER FACTOR 75
0.85
POWER FACTOR 100
0.9
SERVICE FACTOR
1.2
INERTIA KGM2
0.00188 kgm
INERTIA SQ FT
0.04461 sq.ft.
LOCKED ROTOR TIME
6 s
NOISE LEVEL
-
ALTITUDE
1000
DUTY CYCLE
S1
AMBIENT TEMPERATURE
-20C - +50C
DEGREE OF PROTECTION
IP21
NO-LOAD CURRENT
4.00 A
INSULATION CLASS
B
FULL LOAD TORQUE NM
4.03 Nm
FULL LOAD TORQUE FT
2.97 .ft
SLIP
0.0306
DESIGN
-
TEMPERATURE RISE
80 K
BEARINGS D E
6203 2RS
BEARINGS N D E
6203 ZZ
REGREASING INTERVAL D E
-
REGREASING INTERVAL N D E
-
GREASE AMOUNT D E
-
GREASE AMOUNT N D E
-
