Sta-Rite Pumps
L30P4HH-04 STA-RITE 4" Submersible Pump - End Only (3 HP, 12 Stages, 30 GPM @ 320' , 2" Discharge)
L30P4HH-04 STA-RITE 4" Submersible Pump - End Only (3 HP, 12 Stages, 30 GPM @ 320' , 2" Discharge)
SKU:L30P4HH-04
Regular price
$981.08 USD
Regular price
$2,733.00 USD
Sale price
$981.08 USD
Unit price
/
per
Shipping calculated at checkout.
Don't see the price?
Don't see the price?
Certain manufacturers require online sellers to display a price that meets or surpasses the manufacturer's set MAP (Minimum Advertised Price). As we are providing a price lower than the MAP, please Add the Product to Your Cart for pricing details or Request a Quote.
Couldn't load pickup availability
STA-RITE L30P4HH, 3 HP, 12 Stages, 30 GPM Series, 30 GPM @ 320' , 2" Discharge, 3-7/8" Pump Diameter, Stainless Steel Pump Construction,
| Applications | |
| Water systems for residential, industrial, commercial, multiple housing and farm use. | |
| Features | |
| Narrow, 3-3/4" diameter to fit inside 4" well casings | |
| SignaSeal staging system incorporates a harder-than-sand ceramic wear surface and a floating impeller design - which together literally pulverize sand and small debris. This proven feature reduces lock-ups, dry-runs, and abrasive wear. | |
| Floating Stage Design is engineered to transmit forces away from the motor bearing and through the pump housing. This reduces premature wear and misalignment. | |
| Fully-Enclosed Shaft Bearing creates a pressure zone that prevents sand & water from entering. Eliminates wear and misalignment. | |
| Wear Ring forms a seal between impeller hub and suction cap for low friction and no unwanted recirculation of water. | |
| Corrosion resistant 300 grade stainless steel discharge for durability in aggressive water. | |
Specifications | |
Brand |
STA-RITE |
Model Number |
L30P4HH |
Type |
4" Submersible Pump |
STA-Rite Series |
HS Series |
HP |
3 |
Stages |
12 |
GPM Series |
30 |
GPM @ Ft of Head |
30 GPM @ 320' |
Discharge |
2" |
Pump Diameter |
3-7/8" |
Required Motor Diameter |
4" |
Pump Construction |
Stainless Steel |
Contents |
Pump End Only |
Weight lbs. |
15 |
Warranty |
1 Year Warranty |
Notes & Pump Curve |
See Support Documents |
Pump Manual |
See Support Documents |
Support Documents (pdf) |
