L20P4HH-04 STA-RITE 4" Submersible Pump - End Only (3 HP, 17 Stages, 20 GPM @ 420' , 1-1/4" Discharge)

Name: L20P4HH-04 STA-RITE 4" Submersible Pump - End Only (3 HP, 17 Stages, 20 GPM @ 420' , 1-1/4" Discharge)
Brand: Sta-Rite Pumps
SKU: L20P4HH-04
Price: 854.00 USD
Availability: InStock

SKU:L20P4HH-04

$854.00 USD

~~$2,379.00 USD~~ $854.00 USD

Sale Sold out

Shipping calculated at checkout.

Quantity

Don't see the price?

If the item's price is not displayed on this page, you might need to contact us for a quote or add the item to your cart to see the price.

STA-RITE L20P4HH, 3 HP, 17 Stages, 20 GPM Series, 20 GPM @ 420' , 1-1/4" Discharge, 3-7/8" Pump Diameter, Stainless Steel Pump Construction,

Applications
Water systems for residential, industrial, commercial, multiple housing and farm use.

Features
Narrow, 3-3/4" diameter to fit inside 4" well casings
SignaSeal staging system incorporates a harder-than-sand ceramic wear surface and a floating impeller design - which together literally pulverize sand and small debris. This proven feature reduces lock-ups, dry-runs, and abrasive wear.
Floating Stage Design is engineered to transmit forces away from the motor bearing and through the pump housing. This reduces premature wear and misalignment.
Fully-Enclosed Shaft Bearing creates a pressure zone that prevents sand & water from entering. Eliminates wear and misalignment.
Wear Ring forms a seal between impeller hub and suction cap for low friction and no unwanted recirculation of water.
Corrosion resistant 300 grade stainless steel discharge for durability in aggressive water.

Specifications
Brand	STA-RITE
Model Number	L20P4HH
Type	4" Submersible Pump
STA-Rite Series	HS Series
HP	3
Stages	17
GPM Series	20
GPM @ Ft of Head	20 GPM @ 420'
Discharge	1-1/4"
Pump Diameter	3-7/8"
Required Motor Diameter	4"
Pump Construction	Stainless Steel
Contents	Pump End Only
Weight lbs.	15
Warranty	1 Year Warranty
Notes & Pump Curve	See Support Documents
Pump Manual	See Support Documents

Support Documents (pdf)
Notes & Pump Curve
Installation & Parts Manual
