Goulds Pumps
GT07 Goulds Pumps IRRI-GATOR Self-Priming Centrifugal Pump (3/4 HP, 1 Phase, 115/230 Volts, 44 GPM)
GT07 Goulds Pumps IRRI-GATOR Self-Priming Centrifugal Pump (3/4 HP, 1 Phase, 115/230 Volts, 44 GPM)
SKU:GT07
Regular price
$677.10 USD
Regular price
$1,110.00 USD
Sale price
$677.10 USD
Unit price
/
per
Shipping calculated at checkout.
Don't see the price?
Don't see the price?
Certain manufacturers require online sellers to display a price that meets or surpasses the manufacturer's set MAP (Minimum Advertised Price). As we are providing a price lower than the MAP, please Add the Product to Your Cart for pricing details or Request a Quote.
Couldn't load pickup availability
GT07 Goulds Centrifugal Well Pump (GT07, 3/4 HP, 44 Max GPM)
| Applications | |
| Lawn Sprinkling, Irrigation, Air Conditioning Systems, Heat Pumps, Water Transfer and Dewatering | |
| Residential Self Priming Centrifugal Pumps 60 Hz GT Irr-igator | |
| Features | |
| One Year Factory Warranty | |
| Self-Priming Design: Once pump is initially primed, filled with water, it will reprime when the water level rises above the end of the suction pipe. | |
| Serviceable: Back pullout design allows disassembly of pump for service without disturbing piping | |
| Impeller: F.D.A. compliant, glass filled No¬ryl® is corrosion and abrasion resistant. | |
| Diffuser (Guidevane): Diffuser has stainless wear ring for extended performance in abrasive conditions. | |
| Powered for Continuous Operation: Can be oper¬ated continuously without damage. | |
| Corrosion Resistant: Electro-coat paint process is applied inside and out, then baked on. | |
| Mechanical Seal: Carbon/ceramic faces, BUNA elastomers. 300 series stainless steel metal parts. Pump design prevents the seal from running dry. | |
Tech Specs | |
Brand |
Goulds |
Model Number |
GT07 |
Series |
GT Irri-gator |
Type |
Irrigation Self Priming Centrifugal Pump |
HP |
3/4 |
RPM |
3500 |
Voltage |
115/230 |
Phase |
Single |
Hertz |
60 |
Rotation |
Clockwise when viewed from motor end |
Max Temperature |
140 |
Shaft |
Stainless Steel |
Notes |
Built-in overload with automatic reset |
Suction Pipe Connection (in) |
1-1/2" NPT
|
Discharge Pipe Connection (in) |
1-1/2" NPT |
Max Working Pressure (psig) |
125 |
Flow at 5 ft (20 psi) |
44 gpm |
Flow at 10 ft (20 psi) |
41 gpm |
Flow at 15 ft (20 psi) |
36 gpm |
Flow at 20 ft (20 psi) |
31 gpm |
Flow at 25 ft (20 psi) |
34 gpm |
Length (in) |
19 3/16 |
Pump Casing |
Cast iron |
Impeller Material |
Glass filled noryl |
Maximum Flow |
46 gpm |
Maximum Head |
109 ft |
Maximum Water Temperature |
140°F |
Thermal Protection |
Yes |
Parts |
See Below |
Support Documents (pdf) | ||||
| Product Literature | ||||
