Goulds Pumps CB15412MC CentriPro Control Box (1-1/2 HP, Single Phase, 230 Volts, 3 Wire)
Goulds Pumps CB15412MC CentriPro Control Box (1-1/2 HP, Single Phase, 230 Volts, 3 Wire)
SKU:CB15412MC
Regular price
$521.15 USD
Regular price
$570.00 USD
Sale price
$521.15 USD
Unit price
/
per
Shipping calculated at checkout.
Don't see the price?
Don't see the price?
If the item's price is not displayed on this page, you might need to contact us for a quote or add the item to your cart to see the price.
Couldn't load pickup availability
CB15412MC Goulds Pumps Control Box, 3 Wire Submersible Motor (1.5 HP, Single Phase, 230 Volts)
| Applications | |
| 3-wire Submersible Pump Motors | |
| Features | |
| Built-in Magnetic Contactors allow the use of standard pressure switches, prolong switch life and eliminate the need to source and install separate contactors, saving installation time and reducing total system component costs. | |
| Voltage Relay for installer convenienc | |
| 230 volt standard models 208 volt relay, 9K479 available for low voltage applications | |
| Start Capacitors for starting torque | |
| Run Capacitors for efficiency and quiet operation | |
| Type 3R enclosure for indoor or outdoor mounting | |
| Accepts up to #2 AWG wire | |
| Multiple knockouts and two ground terminals | |
| Manual reset overloads on 1 5 HP model | |
Tech Specs | |
Brand |
Goulds Pumps |
Model Number |
CB15412MC |
Type |
Magnetic Contactor Control Box |
Intedend For |
3-Wire Submersible Pump Motors |
HP |
1.5 |
KW |
1.1 |
Phase |
Single |
Volts |
230 |
Replaces GP # |
No Equal |
Replaces RJ # |
No Equal |
Replaces FE # |
No Equal |
Standard Circuit Breaker |
30 |
Standard Fuse |
35 |
Dual Element Time Delay Fuse |
20 |
Enclosure Dimensions W x D x H (in) |
8.1 x 5.9 x 9.3 |
Weight (lbs) |
8 |
Notes |
Control Box Literature |
Support Documents (pdf) | ||||
| Control Box Literature | ||||
