Goulds Pumps AGS1012 Axial Grinder Pump (1 HP, 1 Phase, 230 Volts, Manual Operation)

Goulds Pumps AGS1012, Axial Grinder Pumps Type, AGS Series, 1 HP, 1 Phase, 230 Volts, Manual Operation, 5.5 Maximum Amps, 2" Discharge Size, 20' Power Cord Size,

Applications
The AGS Series grinder pumps feature axial grinder and semi-open impeller technology to easily slice through the solids, flushables and trash found in the modern wastewater stream without roping or clogging. The powerful semi-open impeller and axial grinder reduce waste to a fine slurry to minimize downtime and service issues. AGS Series pumps offer solutions for a range of residential and light commercial applications and are an ideal replacement for 2? discharge sewage pumps. APPLICATIONS: Designed for residential sewage applications where a gravity system is not practical. Ideal for pressure sewage systems.
Features
Design: Capable of grinding domestic sewage in the modern wastewater stream.
Cutter System: Stainless steel, axial lobe-cutter design with 8-hole cutting plate, capable of 4.9 million bites per hour and TDH up to 66 feet.
Impeller: Cast Iron semi open 2 vane impeller.
Casing: Cast iron, volute type for high efficiency. Adaptable for guide rail system.
Motor: Fully submerged in oil-filled chamber. High grade turbine oil surrounds motor for more efficient heat dissipation, permanent lubrication of bearings and mechanical seal, and protection against outside environment.
Motor Shaft: 300 series stainless steel.
Designed for Continuous Operation: Pump ratings are within the motor manufacturer's recommended working limits, can be operated continuously without damage when fully submerged
Capacities: to 53 gpm
Total heads: to 66' TDH
Single mechanical seal: silicon carbide rotary/silicon carbide stationary, 300 series stainless steel metal parts, BUNA-N elastomers
Fasteners: 300 series stainless steel

Specifications
Brand	Goulds Pumps
Catalog Number	AGS1012
Type	Axial Grinder Pumps
Series	AGS
HP	1
Phase	1
Volts	230
RPM	3500
Operation	Manual
Maximum Amps	5.5
Discharge Size	2"
Impeller Diameter	4.25"
Power Cord Size	20'
Notes	See Support Documents
