Goulds Pumps 35GS75, 4" High Capacity Submersible Pump End Only (7-1/2 HP, 36 Stages, 10-50 GPM)

Goulds 35GS75, 4" High Capacity Submersible Pumps Type, 35GS Series, 7.5 HP, 36 Stages, 10-50 GPM, 2" Discharge,

Applications
These below ground pumps are designed for residential and small municipal water supply as well as light irrigation applications. e-GS Pump 35-85 Range (1 10 HP) High Capacity
Features
Innovative, Proven Hydraulics
Up to 13% Efficiency Improvement
Fewer models, same hydraulic coverage.
Premium Stainless Steel casing, motor adapter, discharge head
Built-in Stainless Steel check valve
Convenient Serviceability
Superior Sand Handling
Powered for Continuous Operation: All ratings are within the working limits of the motor as recommended by the motor manufacturer. Pump can be operated continuously without damage to the motor.
Field Serviceable: Units have left hand threads and are field serviceable with common tools and readily available repair parts.
Sand Handling Design: Our face clearance, floating impeller stack has proven itself for over 50 years as a superior sand handling, durable pump design.
FDA Compliant Non-Metallic Parts: Impellers, diffusers and bearing spiders are constructed of glass filled engineered composites. They are corrosion resistant and non-toxic.

Specifications
Brand	Goulds
Catalog Number	35GS75
Type	4" High Capacity Submersible Pumps
Series	35GS
HP	7.5
Stages	36
Length (in)	53
GPM	10-50
Best Efficiency GPM	35
Discharge	2"
Minimum Well Size	4"
Rotation	CCW
Motor	Not Included
Notes	See Support Documents
