Goulds PM45H, ProMax Plus Series, Horizontal Diaphragm Tank, 14 Gallons, 100 PSI Working Pressure, 1" NPTM Connection, 15.375" Diameter, 27.125 " Height

Goulds PM45H, ProMax Plus Series, Horizontal Diaphragm Tank, 14 Gallons, 100 PSI Working Pressure, 1" NPTM Connection, 15.375" Diameter, 27.125 " Height

Features

• Horizontal model comes with a universal jet pump bracket and two (2) bolt-on, corrosion-resistant, high density polypropylene feet for installations with limited headspace, such as under mobile homes
• Powder coated water chamber provides maximum protection against corrosion
• Heavy duty parabolic design has improved diaphragm life by reducing abrasive wear. The diaphragm separates air and water to maintain the tank’s air charge. The Butyl rubber diaphragm is an FDA approved material and also meets NSF / ANSI 61 – G standards
• Maximum working pressure: 100 psi
• 304 stainless-steel connection
• Powder coated exterior: Provides positive protection against corrosion, UV resistance, and certified to ASTM automotive salt test standards.
• Pre-charged to 38 PSI
• Height from floor to center of connection: 9.69"
