GF2024D Century Belt Drive and Blower Motor, Split Phase (1/4 HP, 48/56 Frame, 1725 RPM)
GF2024D Century Belt Drive and Blower Motor, Split Phase (1/4 HP, 48/56 Frame, 1725 RPM)
SKU:GF2024D
Regular price
$0.00 USD
Regular price
Sale price
$0.00 USD
Unit price
/
per
Shipping calculated at checkout.
Don't see the price?
Don't see the price?
If the item's price is not displayed on this page, you might need to contact us for a quote or add the item to your cart to see the price.
Couldn't load pickup availability
Model Number: GF2024D, HP: 1/4, RPM: 1725, Volts: 115/208-230, Frame: 48/56, Enclosure: Open, Type: Split Phase Resilient Base Motor,
| Applications |
| Belt Drive Fans and Blowers, HVAC |
| Features |
| Class B Ins. (Class A see notes); Reversible; Continuous Duty; Sleeve & Ball Bearing; Energy Efficient $ (see notes); 60 HZ; Open and Encloseds |
Tech Specs. | |
Brand |
A.O. Smith |
Model Number |
GF2024D |
HP |
1/4 |
RPM |
1725 |
Volts |
115/208-230 |
Full Load Amps |
5.2/2.6 |
Service Factor |
1.35 |
Frame |
48/56 |
Enclosure |
Open |
Apx. Wt. (lb) |
14 |
Phase |
Split Phase |
Protector |
Auto |
Type |
Split Phase Resilient Base Motor |
Aprox "C" |
9.2 |
Dim "AG" |
7.5 |
Motor Mount |
Resilient Base |
GF2024D |
|
Support Documents (pdf) | ||||
| Product Literature | ||||
