Baldor CECR9304T, SEVERE DUTY MOTORS , 30 HP, 230/460 Volts, 1800 RPM, 286TC Frame,

Applications
Cement, Aggregate, Above ground mining, Bulk material handling, Crushers, belt, conveyors and screens
Features
High torque NEMA Design A, exceeds NEMA Design C torques
1.25 SF up to 100 Hp, 1.15 SF over 100 Hp
Oversized ball bearings up to 50 Hp, ball and roller bearing designs 60 Hp and up. 586/7/8 frames include oversized roller bearing on DE.
586/7/8 frames include oversized, insulated ODE bearing and oversized 4.375 shaft.
IP55 for frame sizes up to L449. IP66 for 586/7/8 frames.
Embossed raised letter, 304 stainless steel nameplates
Inverter ready nameplate
TR catalog numbers are standard roller bearing

Specifications

Brand
Baldor
Catalog Number
CECR9304T
Type
Baldor Crusher Motors
Series
SEVERE DUTY MOTORS
Model
CECR9304T
HP
30
Volts
230/460
RPM
1800
Frame
286TC
C Dim.
27.93
Approx. Weight (lbs)
465
Full Load Efficiency
93.6
Full Load Amps
37
Phase
Three
Enclosure
TEFC
Mount
Foot Mounted
Motor Standards
NEMA
Pulley Face Code
C-Face
Shaft Rotation
Reversible
