BF20086 Century Belt Drive and Blower Motor, Split Phase (1/12 HP, 48Z Frame, 1140 RPM)
BF20086 Century Belt Drive and Blower Motor, Split Phase (1/12 HP, 48Z Frame, 1140 RPM)
[COUNT] shoppers are looking at this right now
No reviews
SKU:BF20086
Regular price
$0.00 USD
Regular price
Sale price
$0.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Model Number: BF20086, HP: 1/12, RPM: 1140, Volts: 115, Frame: 48Z, Enclosure: Open D.P., Type: Split Phase Resilient Base Motor,
| Applications |
| Belt Drive Fans and Blowers, HVAC |
| Features |
| Class B Ins. (Class A see notes); Reversible; Continuous Duty; Sleeve & Ball Bearing; Energy Efficient $ (see notes); 60 HZ; Open and Encloseds |
Tech Specs. | |
Brand |
A.O. Smith |
Model Number |
BF20086 |
HP |
1/12 |
RPM |
1140 |
Volts |
115 |
Full Load Amps |
2.4 |
Service Factor |
1.4 |
Frame |
48Z |
Enclosure |
Open D.P. |
Apx. Wt. (lb) |
16 |
Phase |
Split Phase |
Protector |
Auto |
Type |
Split Phase Resilient Base Motor |
Aprox "C" |
10.3 |
Dim "AG" |
8.4 |
Motor Mount |
Resilient Base |
BF20086 |
|
Support Documents (pdf) | ||||
| Product Literature | ||||
