B82763 Berkeley 6" Submersible Well Pump - End Only (6TS115-100, 115 GPM, 10 HP, 5 Stages, 6" Motor not included, 3" Discharge)

B82763 Berkeley 6" Submersible Well Pump - End Only (6TS115-100, 115 GPM, 10 HP, 5 Stages, 6" Motor not included, 3" Discharge)

The 6TS series pumps feature heavy-duty 304 stainless steel construction and hard chrome wear surfaces that will outperform ordinary fabricated stainless steel pumps in aggressive water conditions. Its state-of-the-art design includes 100% lead-free components with high efficiency and performance.

Features

• Discharge (Female): 3 in.
• Heavy-duty, investment cast 304 stainless steel discharge assures secure connection to drop pipe.  Wrench flats provide positive grip during installation
• State-of-the-art design delivers maximum performance and reliability in the toughest conditions
• 100% Lead-free components meets all U.S. federal guidelines for safe drinking water
• Hard chrome-plated top bearing journal reduces abrasive wear in harsh sandy well conditions
• Self-aligning teflon wear rings improve pump efficiency and durability
• Low-profile stainless steel lead guard aids installation in narrow wells
• Built-in up-thrust protects pump during periods of high demand and start-up preventing pump failure
• 304 stainless steel inlet screen and internal coupling screen prevents entry of abrasives into pump and coupling areas
• Motor is not included
• Couples With 6" Motor

Applications

• Water systems for municipal, multiple housing, commercial, in water fountains, irrigation, mine de-watering, and farm use.
