AMT Pumps 3S7XZR, 3" Trash Pump (5 HP, Hatz Diesel 1B30 Engine, 3" NPT Port, Viton Seal, 2.7 HR Run Time, .79 Tank Size)

AMT Pumps 3S7XZR, 3" Trash Pump (5 HP, Hatz Diesel 1B30 Engine, 3" NPT Port, Viton Seal, 2.7 HR Run Time, .79 Tank Size)

👁️ [COUNT] People are currently viewing this product.

3S7XZR

$5,470.67 USD
$8,206.00 USD $5,470.67 USD
Sale Sold out
Shipping calculated at checkout.

Don't see the price?

If you are unable to find the price for this item on our page, please contact us directly for a quote.

Some products require you to ADD TO CART to see the price.

Tax

NY, NJ and CT will be charged tax on most orders.

Sales tax will need to be collected on all AMT and Jorc products, regardless of the destination state.

* If you are tax exempt and would like to place an order, email your tax exempt form to Sales@kgpowersystems.com.

** Taxes may be applied after an order is placed.

AMT 3S7XZR, 3" Trash Pumps, 5 HP, 3" NPT, Hatz Diesel 1B20, Viton / SIC-SIC Seal,
Applications
IPT Portable High Volume, Self-priming Centrifugal Trash pumps come standard with a cast iron impeller to resist abrasion and one tool serviceability for easy cleanout. All pumps feature aluminum housing, cast iron wearparts, built-in check valve, suction strainer and heavy duty steel roll frame. Heavy duty cast iron flanges with male NPT threads that rotates in 90 increments. Easy access fill plug on discharge port.
Features
Cast Iron Impeller
One Tool Serviceability Tool Included with Engine Driven Models
Silicon Carbide Mechanical Seal with Graphite Impregnated Seat and Viton Elastomers
Built-in EPDM/EPR Check Valve
Removable/Replaceable Cast Iron Suction/Discharge Ports
Discharge Port Rotates in 90 Increments
Vibration Dampening Feet
Maximum Temperature 180 F

Specifications

Brand
AMT
Catalog Number
3S7XZR
Type
Engine Driven Self-Priming Trash Pumps
Series
3" Trash Pumps
HP
5 HP
Curve
B
Port
3" NPT
Driver
Hatz Diesel 1B30
Seal
Viton / SIC-SIC
Run Time (Hours)
2.7
Tank Size (Gal/Ltr.)
0.79/3.0
Ship Wt. (Lbs.)
135
Discharge
3" NPT
Suction
3" NPT
Oil Alert
Not Included
L
31"
W
22.5"
H
23.6"
Warranty
1 Year
Notes
See Support Documents
