Leeson Motors 102921, General Purpose, C4T17NK3, 1/3 HP, S56C Frame, 1725RPM, 208-230/460V, TENV
| Applications | |
| ODP Models: For use where water and dust exposure is moderate. Ideally suited for use on pumps, compressors, blowers, fans, and other direct or belt-driven applications.TEFC Models: For use where exposure to water, dust and corrosives exists. Ideally suited for use on pumps, compressors, blowers, fans, conveyors, machine tools and other direct or belt-driven applications. | |
| Features | |
| Durable rolled steel frame | |
| Class B insulation | |
| High-quality ball bearings | |
| Easy-to-read nameplate | |
| Some 56 frame motors have a 56, 56H, 143T and 145T combination base with 12 mounting holes for flexible installation. | |
| UL Recognized Component Listing and CSA approval. | |
| Warranty 12 months from date of first use or 18 months from date of manufacture, whichever comes first. | |
Specifications | |
Brand |
Leeson Motors |
Catalog Number |
102921 |
Type |
Leeson Electric Motor |
Series |
General Purpose |
Model Number |
C4T17NK3 |
HP |
1/3 |
Frame |
S56C |
RPM |
1725RPM |
Voltage |
208-230/460V |
Enclosure |
TENV |
Warranty |
1 Year |
Notes |
See Support Documents |
Support Documents (pdf) | ||||
