SPP-231P Pentair Pentek Single-Phase Pump Protection (1/2-1HP, 230V, Insider Enclosure Type)
Pentek offers a full range of 1/3 - 15 HP single-phase protectors for residential, commercial, multiple housing and farm water systems applications where a 4" submersible, 2- and 3-wire motor is used and for aboveground pressure-boost applications.
Pentek offers 5 models for your application needs based on HP and Motor Type: SPP-111, SPP-111-3RL, SPP-231, SPP-233 and SPP-235.
Protects Pumps – from dry well, overcurrent (jammed impeller), flow restriction (dead head), overvoltage, under voltage, rapid cycling.
| CATALOG NUMBER | SPP-231P | ||
| ENCLOSURE TYPE | Insider | ||
| 1-PHASE LINE VOLTAGE | 230VAC | ||
| LOAD RANGE | 1/2 - 1 HP | ||
| FREQUENCY | 50 - 60Hz | ||
| OPERATING POINTS | |||
| Overload (% of Cal. Point) | 125% | ||
| Over-voltage Reset Point | 265VAC | ||
| Under-voltage Reset Point | 190VAC | ||
| Trip Delay (Overload) | 10 sec. | ||
| Trip Delay (Dry Well) | 2 sec. | ||
| Optional Trip Delay | 4 sec. | ||
| RESTART DELAY TIME | |||
| Over/Under Voltage Delay | 5 Sec. | ||
| All Other Faults (Dry Well REC. Timer) | 2 - 225 min. | ||
| Output Contact Rating (SPST) | 1 HP (17 amps max.) | ||
| Power Consumption (max.) | 5 amps | ||
| Weight w/o Enclosure | 10 oz. | ||
| Weight w/Enclosure | - | ||
| Enclosure Size | 2.2” x 2.8” | ||
