• Goulds Pumps, CentriPro CB15MC3RF Magnetic Contactor Control Boxes for 6" Submersible Motors (15 HP, 230 Volts, Single Phase)
1 1

Goulds Pumps

Goulds Pumps, CentriPro CB15MC3RF Magnetic Contactor Control Boxes for 6" Submersible Motors (15 HP, 230 Volts, Single Phase)

Goulds Pumps, CentriPro CB15MC3RF Magnetic Contactor Control Boxes for 6" Submersible Motors (15 HP, 230 Volts, Single Phase)

CB15MC3RF

$1,549.43 USD
$2,683.00 USD $1,549.43 USD
Oferta Agotado
Los gastos de envío se calculan en la pantalla de pago.

Don't see the price?

Certain manufacturers require online sellers to display a price that meets or surpasses the manufacturer's set MAP (Minimum Advertised Price). As we are providing a price lower than the MAP, please Add the Product to Your Cart for pricing details or Request a Quote.

Goulds CB15MC3RF, Magnetic Contactor Control Boxes for FM Series 6" Single Phase Motors Type, 15 HP, 230 Volts, Single Phase,
Applications
FOR 6", 5-15 HP CENTRIPRO SUBMERSIBLE MOTORS
Features
IMPORTANT: Use these control boxes on only CentriPro (Hitachi) motors. Franklin Electric control boxes will not work and will void the CentriPro warranty. Do not use these control boxes on Franklin Electric 6" motors as the overloads and capacitors are not the same as used by FE, using these will void FE's warranty.
Overload circuit breaker is rated at 100 amps versus 90 amp standard in CB15MC. Use in areas with high ambient temperatures to reduce nuisance tripping.
Built-in Magnetic Contactors allow the use of standard pressure switches, prolong switch life and eliminate the need to source and install separate contactors, saving installation time and reducing total system component costs.
Voltage Relay for installer convenience
Start Capacitors for starting torque
Run Capacitors for efficiency and quiet operation
Type N3R enclosure for indoor or outdoor mounting
Multiple knockouts and two ground terminals
Manual reset overload circuit breakers
TESTED TO UL AND CSA STANDARDS BY UL.

Specifications

Brand
Goulds
Catalog Number
CB15MC3RF
Type
Magnetic Contactor Control Boxes for FM Series 6" Single Phase Motors
Use on Motor No.
6F151
HP
15
Volts
230
Phase
Single
Start Caps
216-260
Run Caps
(2) 70
Contactor Rating
90A
Overlead Circuit Breaker
80A
Enclosure Dimensions
17.5" H x 11" W x 6.7" D
Shipping Weight (lbs)
27
Additional
FM Series control boxes are designed for use with FM Series 6" motors only.
Warranty
1 year
Notes
See Support Documents Below
