Goulds Pumps, CentriPro CB10MC3RF Magnetic Contactor Control Boxes for 6" Submersible Motors (10 HP, 230 Volts, Single Phase)
Goulds Pumps, CentriPro CB10MC3RF Magnetic Contactor Control Boxes for 6" Submersible Motors (10 HP, 230 Volts, Single Phase)
👁️
[COUNT] People are currently viewing this product.
No reviews
SKU:CB10MC3RF
Precio habitual
$1,747.46 USD
Precio habitual
$2,444.00 USD
Precio de oferta
$1,747.46 USD
Los gastos de envío se calculan en la pantalla de pago.
Cantidad
No se pudo cargar la disponibilidad de retiro
Don't see the price?
Don't see the price?
If you are unable to find the price for this item on our page, please contact us directly for a quote.
Some products require you to ADD TO CART to see the price.
Tax
Tax
NY, NJ and CT will be charged tax on most orders.
* If you are tax exempt, email your tax form to Sales@kgpowersystems.com
Goulds CB10MC3RF, Magnetic Contactor Control Boxes for FM Series 6" Single Phase Motors Type, 10 HP, 230 Volts, Single Phase,
| Applications | |
| FOR 6", 5-15 HP CENTRIPRO SUBMERSIBLE MOTORS | |
| Features | |
| IMPORTANT: Use these control boxes on only CentriPro (Hitachi) motors. Franklin Electric control boxes will not work and will void the CentriPro warranty. Do not use these control boxes on Franklin Electric 6" motors as the overloads and capacitors are not the same as used by FE, using these will void FE's warranty. | |
| Overload circuit breaker is rated at 100 amps versus 90 amp standard in CB15MC. Use in areas with high ambient temperatures to reduce nuisance tripping. | |
| Built-in Magnetic Contactors allow the use of standard pressure switches, prolong switch life and eliminate the need to source and install separate contactors, saving installation time and reducing total system component costs. | |
| Voltage Relay for installer convenience | |
| Start Capacitors for starting torque | |
| Run Capacitors for efficiency and quiet operation | |
| Type N3R enclosure for indoor or outdoor mounting | |
| Multiple knockouts and two ground terminals | |
| Manual reset overload circuit breakers | |
| TESTED TO UL AND CSA STANDARDS BY UL. | |
Specifications | |
Brand |
Goulds |
Catalog Number |
CB10MC3RF |
Type |
Magnetic Contactor Control Boxes for FM Series 6" Single Phase Motors |
Use on Motor No. |
6F101 |
HP |
10 |
Volts |
230 |
Phase |
Single |
Start Caps |
216-260 |
Run Caps |
(2) 50 |
Contactor Rating |
70A |
Overlead Circuit Breaker |
60A |
Enclosure Dimensions |
17.5" H x 11" W x 6.7" D |
Shipping Weight (lbs) |
27 |
Additional |
FM Series control boxes are designed for use with FM Series 6" motors only. |
Warranty |
1 year |
Notes |
See Support Documents Below |
Support Documents (pdf) |
