• Goulds Pumps, CentriPro CB05MC3R Magnetic Contactor Control Boxes for 6" Submersible Motors (5 HP, 230 Volts, Single Phase)
1 1

Goulds Drives & Controls

Goulds Pumps, CentriPro CB05MC3R Magnetic Contactor Control Boxes for 6" Submersible Motors (5 HP, 230 Volts, Single Phase)

Goulds Pumps, CentriPro CB05MC3R Magnetic Contactor Control Boxes for 6" Submersible Motors (5 HP, 230 Volts, Single Phase)

👁️ [COUNT] People are currently viewing this product.

CB05MC3R

$1,119.69 USD
$1,566.00 USD $1,119.69 USD
Oferta Agotado
Los gastos de envío se calculan en la pantalla de pago.

Don't see the price?

If you are unable to find the price for this item on our page, please contact us directly for a quote.

Some products require you to ADD TO CART to see the price.

Tax

NY, NJ and CT will be charged tax on most orders.

Sales tax will need to be collected on all AMT and Jorc products, regardless of the destination state.

* If you are tax exempt and would like to place an order, email your tax exempt form to Sales@kgpowersystems.com.

** Taxes may be applied after an order is placed.

Goulds CB05MC3R, Magnetic Contactor Control Boxes for Centripro / Hitachi 6" Single Phase Motors Type, 5 HP, 230 Volts, Single Phase,
Applications
FOR 6", 5-15 HP CENTRIPRO SUBMERSIBLE MOTORS
Features
IMPORTANT: Use these control boxes on only CentriPro (Hitachi) motors. Franklin Electric control boxes will not work and will void the CentriPro warranty. Do not use these control boxes on Franklin Electric 6" motors as the overloads and capacitors are not the same as used by FE, using these will void FE's warranty.
Overload circuit breaker is rated at 100 amps versus 90 amp standard in CB15MC. Use in areas with high ambient temperatures to reduce nuisance tripping.
Built-in Magnetic Contactors allow the use of standard pressure switches, prolong switch life and eliminate the need to source and install separate contactors, saving installation time and reducing total system component costs.
Voltage Relay for installer convenience
Start Capacitors for starting torque
Run Capacitors for efficiency and quiet operation
Type N3R enclosure for indoor or outdoor mounting
Multiple knockouts and two ground terminals
Manual reset overload circuit breakers
TESTED TO UL AND CSA STANDARDS BY UL.

Specifications

Brand
Goulds
Catalog Number
CB05MC3R
Type
Magnetic Contactor Control Boxes for Centripro / Hitachi 6" Single Phase Motors
Use on Motor No.
6M051
HP
5
Volts
230
Phase
Single
Start Caps
189-227uf / 330V
Run Caps
30 / 440V
Contactor Rating
30A
Overlead Circuit Breaker
30A
Enclosure Dimensions
12.5" H x 11" W x 6.7" D
Shipping Weight (lbs)
15
Additional
Use these control boxes on only CentriPro (Hitachi) motors. Franklin Electric control boxes will not work and will void the CentriPro warranty.
Warranty
1 year
Notes
See Support Documents Below
