M05421 Goulds CentriPro 4" Submersible Well Motor (1/2 HP, 1 Phase, 115 Volts, 2 Wire, Stainless Steel Casing)

M05421 Goulds CentriPro 4" Submersible Well Motor (1/2 HP, 1 Phase, 115 Volts, 2 Wire, Stainless Steel Casing)

[COUNT] shoppers are looking at this right now

M05421

$642.60 USD
$1,071.00 USD $642.60 USD
Oferta Agotado
Los gastos de envío se calculan en la pantalla de pago.

View Price in Cart

M05421 Goulds 4" Motor (1/2 HP, 1 Phase, 115 Volts, 2 Wire)

Applications
Below ground well pump motor for residential and small municipal water supply as well as light irrigation applications.
Features
Stainless Steel Casing
Stainless Steel Parts
Water Lubricated
Lightning/Surge Protection built-in
CSA Certified
* Motor-end only. The wet end is not included.

Tech Specs

Brand
Goulds Pumps
Model Number
M05421
Brand
Goulds Pumps
Type
2 Wire Submersible Pump Motor
HP
1/2
Phase
1
Volts
115
Wire Qty.
2 Wire
Amps
7.4
Full Load Watts
845
Thrust Rating
700
Service Factor
1.6
Locked Rotor Amps
36.4
Winding Resistance
1.3-1.8
Full Load Efficiency %
49
Service Factor Efficiency %
61
Full Load Power Factor %
99
Service Factor Power Factor %
99
KVA Code
K
Length (in)
11
Service Factor Watts
1088
Amps
9.5
Notes
See Goulds Literature
