D12ARM2N9 US Motor Special Application Commercial Gate Motor (1/2 HP, ODP, 1625 RPM, 1 Phase, 115V, 56 Frame)
D12ARM2N9 US Motor Special Application Commercial Gate Motor (1/2 HP, ODP, 1625 RPM, 1 Phase, 115V, 56 Frame)
[COUNT] shoppers are looking at this right now
No reviews
SKU:D12ARM2N9
Precio habitual
$611.52 USD
Precio habitual
$0.00 USD
Precio de oferta
$611.52 USD
Los gastos de envío se calculan en la pantalla de pago.
Cantidad
No se pudo cargar la disponibilidad de retiro
D12ARM2N9 US Motor (1/2 HP, ODP, 1625 RPM, 1 Phase, 115V, 56 Frame)
| Model_Number: | K055GDW8143015H |
| PRODUCT NAME: | .5 HP - OPEN - 1625 |
| PHASETYPE: | 1_PERMANENT SPLIT CA |
| MOTOR ENCLOSURE: | OPEN |
| HORSEPOWER: | .5 |
| KILOWATTS: | 0.4 |
| POLES: | 4 |
| NUMBER SPEEDS: | 1 |
| RPM: | 1625 |
| RPM 2: | 1325 |
| HERTZ: | 60 |
| HERTZ 2: | 50 |
| VOLTS PRIMARY: | 115 V |
| VOLTS : | 115 |
| FRME : | 56 |
| STATOR DIAMETER: | 5.5 |
| STACK: | 1.75 |
| MOUNTING: | RESILIENT |
| MOTOR TYPE: | FHP |
| OPPOSITE END BEARING: | BALL |
| SHAFT END BEARING: | BALL |
| AMBIENT: | 25 |
| ROTATION: | REVERSIBLE |
| SERVICE FACTOR: | 1 |
| RUNCAPMFD: | 65 |
| RUNCAPVOLTS: | 240 |
| SHIPPING WEIGHT: | 20 |
| THERMAL PROTECTION: | MANUAL RESET |
| BREAKDOWN TORQUE: | 47.35 |
| BREAKDOWN TORQUE UOM: | OZFT |
| LOCKED ROTOR TORQUE: | 30.52 |
| LOCKED ROTOR TORQUE UOM: | OZFT |
| INSULATION CLASS: | B |
| KVA CODE LETTER: | A |
| LOCKED ROTOR AMPS: | 10.45 |
| FULL LOAD AMPS PRIMARY: | 5.0/5.7 |
| SERVICE FACTOR AMPS PRIMARY: | 5.0/5.7 |
