BVM15-9-300 Berkeley Vertical Multi-Stage Pump (20 HP, 9 Stages, Viton Flange, Cast Iron, Pump End Only)
BVM15-9-300 Berkeley Vertical Multi-Stage Pump (20 HP, 9 Stages, Viton Flange, Cast Iron, Pump End Only)
👁️
[COUNT] People are currently viewing this product.
No reviews
SKU:BVM15-9-300
Precio habitual
$5,363.08 USD
Precio habitual
$9,960.00 USD
Precio de oferta
$5,363.08 USD
Precio unitario
/
por
Los gastos de envío se calculan en la pantalla de pago.
No se pudo cargar la disponibilidad de retiro
Don't see the price?
Don't see the price?
If you are unable to find the price for this item on our page, please contact us directly for a quote.
Some products require you to ADD TO CART to see the price.
Tax
Tax
NY, NJ and CT will be charged tax on most orders.
Sales tax will need to be collected on all AMT and Jorc products, regardless of the destination state.
* If you are tax exempt and would like to place an order, email your tax exempt form to Sales@kgpowersystems.com.
** Taxes may be applied after an order is placed.
Berkeley BVM15-9-300, Vertical Multistage Centrifugal Pumps Type, BVM15 Series, 20 HP, 9 Stages, Pump End Only, Viton Flange, 1 Phase, Voltage, Cast Iron Material,
| Applications | |
| The Berkeley BVM Series are non-self priming vertical multistage pump of in-line design, with flange, NPT and grooved connections and stainless steel stage construction. Premium efficiency pump motors are available. Pump stub shaft and motor shaft of the NEMA standard motor are directly close coupled. Applications: Water supply, Pressure boosting systems, Water treatment/filtration, Irrigation, High pressure washes, Liquid transfer, Firefighting system, Boiler feed. | |
| Features | |
| Flanged, NPT or grooved connections | |
| Cartridge Mechanical Seal - can be replaced easily without dismantling the pump | |
| Continuous-duty, high-efficiency designs | |
| Heavy-duty cast motor bracket insures proper motor alignment | |
| High-thrust Open Drip or TEFC enclosure motor options | |
| Versatility in performance and design | |
| Retrofits easily in existing and new installations, reducing valuable downtime | |
| Lower operating costs | |
Specifications | |
Brand |
Berkeley |
Catalog Number |
BVM15-9-300 |
Type |
Vertical Multistage Centrifugal Pumps |
Series |
BVM15 |
HP |
20 |
Stages |
9 |
Enclosure |
Pump End Only |
Flange |
Viton |
Phase |
1 |
Material |
Cast Iron |
S.F |
1.15 |
Hz |
60 |
Notes |
See Support Documents |
Support Documents (pdf) | ||||
