ASB130 US Motor AQUA-SHIELD 56 Frame Pool & Spa Motor (2.6 HP, ODP, 3450 RPM)
ASB130 US Motor AQUA-SHIELD 56 Frame Pool & Spa Motor (2.6 HP, ODP, 3450 RPM)
[COUNT] shoppers are looking at this right now
No reviews
SKU:ASB130
Precio habitual
$472.87 USD
Precio habitual
$0.00 USD
Precio de oferta
$472.87 USD
Los gastos de envío se calculan en la pantalla de pago.
Cantidad
No se pudo cargar la disponibilidad de retiro
ASB130 US Motor AQUA-SHIELD 56 Frame Pool & Spa Motor (2.6 HP, ODP, 3450 RPM)
| Model_Number: | K063DGE5166023J |
| PRODUCT NAME: | 2.6 HP - ODP - 3450 |
| PHASETYPE: | 1_PERMANENT SPLIT CA |
| MOTOR ENCLOSURE: | ODP |
| HORSEPOWER: | 2.6 |
| POLES: | 2 |
| NUMBER SPEEDS: | 1 |
| RPM: | 3450 |
| HERTZ: | 60 |
| VOLTS PRIMARY: | 230 V |
| VOLTS : | 230 |
| FRME : | 56 |
| SHAFT CODE: | J |
| STATOR DIAMETER: | 6.3 |
| STACK: | 2.75 |
| MOUNTING: | C-FACE |
| MOTOR TYPE: | FHP |
| OPPOSITE END BEARING: | 6203 |
| SHAFT END BEARING: | 6203 |
| AMBIENT: | 50 |
| ROTATION: | CW LEAD END |
| RUNCAPMFD: | 35 |
| RUNCAPVOLTS: | 370 |
| SHIPPING WEIGHT: | 30 |
| THERMAL PROTECTION: | AUTOMATIC RESET |
| BREAKDOWN TORQUE: | 140.6 |
| BREAKDOWN TORQUE UOM: | OZFT |
| LOCKED ROTOR TORQUE: | 11.71 |
| LOCKED ROTOR TORQUE UOM: | OZFT |
| INSULATION CLASS: | B |
| KVA CODE LETTER: | G |
| LOCKED ROTOR AMPS: | 49.37 |
| FULL LOAD AMPS PRIMARY: | 11.5 |
