ARB2016S Century Belt Drive and Blower Motor, Split Phase (1/6 HP, 48 Frame, 1140 RPM)
ARB2016S Century Belt Drive and Blower Motor, Split Phase (1/6 HP, 48 Frame, 1140 RPM)
SKU:ARB2016S
Precio habitual
$0.00 USD
Precio habitual
Precio de oferta
$0.00 USD
Precio unitario
/
por
Don't see the price?
Don't see the price?
Certain manufacturers require online sellers to display a price that meets or surpasses the manufacturer's set MAP (Minimum Advertised Price). As we are providing a price lower than the MAP, please Add the Product to Your Cart for pricing details or Request a Quote.
Model Number: ARB2016S, HP: 1/6, RPM: 1140, Volts: 115/208-230, Frame: 48, Enclosure: TEAO, Type: Split Phase Resilient Base Motor,
Applications |
Belt Drive Fans and Blowers, HVAC |
Features |
Class B Ins. (Class A see notes); Reversible; Continuous Duty; Sleeve & Ball Bearing; Energy Efficient $ (see notes); 60 HZ; Open and Encloseds |
Tech Specs. | |
Brand |
A.O. Smith |
Model Number |
ARB2016S |
HP |
1/6 |
RPM |
1140 |
Volts |
115/208-230 |
Full Load Amps |
4.6/2.2-2.3 |
Service Factor |
1 |
Frame |
48 |
Enclosure |
TEAO |
Apx. Wt. (lb) |
18 |
Phase |
Split Phase |
Protector |
Auto |
Type |
Split Phase Resilient Base Motor |
Aprox "C" |
9.5 |
Dim "AG" |
7.9 |
Motor Mount |
Resilient Base |
ARB2016S |
Support Documents (pdf) | ||||
Product Literature |
