96160157 Grundfos 3" Multi-Stage Submersible Groundwater Pump and Motor (Model 22 SQ10-190, 1 HP, 1 Phase, 200-240 Volt, 5 Stage, 1-1/2" NPT Outlet, 22 GPM at 200ft Head)
96160157 Grundfos 3" Multi-Stage Submersible Groundwater Pump and Motor (Model 22 SQ10-190, 1 HP, 1 Phase, 200-240 Volt, 5 Stage, 1-1/2" NPT Outlet, 22 GPM at 200ft Head)
SKU:96160157
No se pudo cargar la disponibilidad de retiro
Don't see the price?
Don't see the price?
If you are unable to find the price for this item on our page, please contact us directly for a quote.
Some products require you to ADD TO CART to see the price.
Tax
Tax
NY, NJ and CT will be charged tax on most orders.
* If you are tax exempt, email your tax form to Sales@kgpowersystems.com
96160157 Grundfos 3" Multi-Stage, Submersible Groundwater Pump and Motor (Model 22 SQ10-190, 1 HP, 1 Phase, 200-240 Volt, 5 Stage, 1-1/2" NPT Outlet, 22 GPM at 200ft Head)
3" multi-stage, submersible pump designed for domestic water supply, liquid transfer in tanks, irrigation and environmental applications. The pump has "floating" impellers, each with its own tungsten carbide/ceramic bearing.
The pump features soft starting and protection against dry-running, up thrust, overvoltage, under voltage, overload and overtemperature.
The motor is a single-phase motor of the permanent magnet rotor type ensuring optimum efficiency within a wide load range. The motor is fitted with a replaceable end cover with socket.
Suitable for:
- Domestic ground water intake
- Domestic rainwater harvesting
- Ground water intake
Features:
- Time-tested, reliable performance and rugged 304 stainless steel construction
- Easy to install, simple constant-speed, 1-phase, 2-wire (+ ground) design - ideal drop-in replacement for similar models, no complex wiring
- Can be wired to a standard Square D or similar pressure switch when used with a well tank (such as Well-X-Trol or similar)
- Higher efficiency than conventional pumps thanks to the permanent magnet motor - for added energy savings and slimmer design
- Enhanced sand wear resistance thanks to the floating impellers with tungsten carbide bearings
- Dry-running protection with auto-retry
- Unique Soft Start feature ensures a smooth acceleration, prevents overload during start-up, reduces motor wear and system stress (longer life and no water hammer)
- Overvoltage and under voltage protection with auto cut-in (retry)
- Overload and thermal protection (overheating and freezing) with auto-retry
- Built-in check valve
