388K-98 AMT 1-1/2" Stainless Steel Inline Centrifugal Pump (2 HP, 56J Frame, 115/208-230 VAC/60 Hz, 1 Phase, Stainless Casing)
388K-98 AMT 1-1/2" Stainless Steel Inline Centrifugal Pump (2 HP, 56J Frame, 115/208-230 VAC/60 Hz, 1 Phase, Stainless Casing)
👁️
[COUNT] People are currently viewing this product.
No reviews
SKU:388K-98
Precio habitual
$814.67 USD
Precio habitual
$1,222.00 USD
Precio de oferta
$814.67 USD
Precio unitario
/
por
Los gastos de envío se calculan en la pantalla de pago.
No se pudo cargar la disponibilidad de retiro
Don't see the price?
Don't see the price?
If you are unable to find the price for this item on our page, please contact us directly for a quote.
Some products require you to ADD TO CART to see the price.
Tax
Tax
NY, NJ and CT will be charged tax on most orders.
Sales tax will need to be collected on all AMT and Jorc products, regardless of the destination state.
* If you are tax exempt and would like to place an order, email your tax exempt form to Sales@kgpowersystems.com.
** Taxes may be applied after an order is placed.
AMT 388K-98, 1-1/2" STAINLESS STEEL INLINE CENTRIFUGAL PUMP Type, 2 HP, 56J Frame, 115/208-230 VAC/60 Hz, 1 Phase, Stainless Casing,
| Applications | |
| AMT SS Centrifugal pumps are designed for use with most gravity fed service applications requiring chemical processing and dirty water transfer. All models are fitted with a self-cleaning stainless steel impeller for maximum 1/8" diameter solids handling. Pumps are designed to handle liquids with solids content or dissolved solids and debris. Units feature pull from-rear design for easy servicing without removing piping. Pumps are not self-priming and require flooded suction. | |
| Features | |
| Stainless Steel Construction | |
| Max Temp 180 Degrees F. | |
| Self-Cleaning | |
| 1/8? Diameter Solids Handling Stainless Steel Impeller | |
| Buna-N Mechanical Seal and O-Ring | |
| 1-1/2" x 1-1/2" NPT Thread | |
| Pull-from-Rear Design for Easy Servicing Without Removing Piping | |
|
Specifications |
|
|
Brand
|
AMT
|
|
Catalog Number
|
388K-98
|
|
Type
|
1-1/2" STAINLESS STEEL INLINE CENTRIFUGAL PUMP
|
|
Series
|
STRAIGHT INLINE CENTRIFUGAL ELECTRIC DRIVEN PUMPS
|
|
HP
|
2
|
|
Frame
|
56J
|
|
VAC/60 Hz
|
115/208-230
|
|
Phase
|
1
|
|
Casing
|
Stainless
|
|
Max Suction Lift
|
6"
|
|
Discharge
|
1-1/2"
|
|
Suction
|
1-1/2"
|
|
Notes
|
See Support Documents
|
|
Support Documents (pdf)
|
||||
|
|
||||
