Berkeley Pumps

10MS Berkeley Vertical Multi-Stage Deep Well Jet Pumps (1 HP, 115/230 Voltage, 60 PSI, 60 Hz, Cast Iron Body, MS Series)

10MS Berkeley Vertical Multi-Stage Deep Well Jet Pumps (1 HP, 115/230 Voltage, 60 PSI, 60 Hz, Cast Iron Body, MS Series)

👁️ [COUNT] People are currently viewing this product.

10MS

$1,196.51 USD
$2,456.00 USD $1,196.51 USD
Oferta Agotado
Los gastos de envío se calculan en la pantalla de pago.

Don't see the price?

If you are unable to find the price for this item on our page, please contact us directly for a quote.

Some products require you to ADD TO CART to see the price.

Tax

NY, NJ and CT will be charged tax on most orders.

Sales tax will need to be collected on all AMT and Jorc products, regardless of the destination state.

* If you are tax exempt and would like to place an order, email your tax exempt form to Sales@kgpowersystems.com.

** Taxes may be applied after an order is placed.

Berkeley 10MS, Vertical Multi-Stage Deep Well Jet Pumps Type, MS Series, 1 HP, 115/230 Voltage, 60 PSI, 60 Hz, Cast Iron Body,
Applications
The MS Series Vertical Jet Pumps are the industry standard deep well jet pumps for over-the-well "bolt-on" installations. These pumps include the pre-plumbed BERKELEY external automatic regulator, pressure gauge, pressure switch, and a complete line of casing adapters to drive the 4" double pipe or 2" and 3" single pipe jet packages. APPLICATIONS: Water systems and sprinklingfor homes, farms and cottages.
Features
Automatic Pressure Regulator With a Faster Acting and Quieter Design Eliminates "Hunting" For the Correct Drive Pressure. New Improved Stem and Guide are Precisely Molded to Assure Efficient, Trouble-Free Performance On All Deep Wells
Quality Built Precision Machined, Close Grained Cast Iron Body and Base Are Specially Treated to Resist Corrosion
Precision Molded Noryl Impellers for Perfect Balance. Ultra-Smooth for Highest Performance and Efficiency
High Quality Pressure Switch With Adjustable Differential and Cut-In/Cut-Out Pressure Settings
Superior Insulation Materials Protect Motor Against Excessive Moisture and Contaminants to Ensure Prolonged Motor Life
Mechanical Shaft Seal Has Precision Lapped and Highly Polished Carbon-Ceramic Surfaces. Internal Design Guarantees Continuous Water Lubrication For Maximum Protection
Dustproof Motor Cover Protects All Electrical Components From Dirt, Dust, and Insects. Ventilating Air Cannot Contaminate Vital Switching Components
Dynamically Balanced Rotor is Die Cast Under High Pressure For Uniform Performance and Greater Efficiency
Heavy-Duty Permanently Lubricated Ball Bearings Are Extensively Tested To Ensure Extended Life and Smooth, Quiet Operation
One-Piece Stainless Steel Threaded Pump and Motor Shaft for Positive Impeller Drive and Alignment.

Specifications

Brand
Berkeley
Catalog Number
10MS
Type
Vertical Multi-Stage Deep Well Jet Pumps
Series
MS
HP
1
Voltage
115/230
PSI
60
Suction
1-1/4"
Discharge
1"
Drive
1-1/4"
Hz
60
Body
Cast Iron
Pump and Motor Shaft
416 Stainless Steel
Impeller
Noryl (R)
Diffuser
Close-Grained Cast Iron

  • Questions about this product? Contact our team!
  • This item is direct shipped from the manufacturer. Lead times will vary. Contact for availability.
  • ALL IMAGES SHOWN ON OUR WEBSITE ARE FOR ILLUSTRATION PURPOSE ONLY AND MAY NOT BE AN EXACT REPRESENTATION OF THE PRODUCT. ACTUAL PRODUCTS MAY VARY FROM THE IMAGES SHOWN.
