03718ET3Y225S/M-W22 WEG Motor (50 HP, 1800//1500 RPM, 3 Phase, 225S/M Frame, TEFC Enclosure, 460//380-415/660-690 Voltage)
03718ET3Y225S/M-W22 WEG Motor (50 HP, 1800//1500 RPM, 3 Phase, 225S/M Frame, TEFC Enclosure, 460//380-415/660-690 Voltage)
No reviews
SKU:03718ET3Y225S/M-W22
Precio habitual
$5,089.59 USD
Precio habitual
Precio de oferta
$5,089.59 USD
Precio unitario
/
por
Los gastos de envío se calculan en la pantalla de pago.
Don't see the price?
Don't see the price?
Certain manufacturers require online sellers to display a price that meets or surpasses the manufacturer's set MAP (Minimum Advertised Price). As we are providing a price lower than the MAP, please Add the Product to Your Cart for pricing details or Request a Quote.
No se pudo cargar la disponibilidad de retiro
WEG 03718ET3Y225S/M-W22, 50 HP, 37 KW, 1800//1500 RPM, 3 Phase, 225S/M Frame, TEFC Enclosure, 460//380-415/660-690 Voltage
| Applications | |
| This line is designed and built according to European IEC34 and IEC79 standards. | |
| Features | |
| 60 Hz (1.15 service factor) and 50 Hz (1.0 service factor) | |
| Class F insulation (Impregnation Resin and Magnet wire are class H) | |
| F2 mounted as standard (F1 convertible) | |
| Stainless Steel Nameplate - Laser etched with High contrast background | |
| Regreasable ball bearings (Frames 160 and up) | |
| Gasketed conduit box | |
| Suitable for WYE/Delta Start (W and Y voltage code motors) | |
Specifications | |
Brand |
WEG |
Catalog Number |
03718ET3Y225S/M-W22 |
Type |
IEC Tru-Metric Motor |
HP |
50 |
KW |
37 |
RPM |
1800//1500 |
Phase |
3 |
C Dimension |
34.882 |
Service Factor |
1.25 |
Frame |
225S/M |
Enclosure |
TEFC |
Full Load Amps |
58.5 |
Mount |
Foot Mount |
Voltage |
460//380-415/660-690 |
Warranty |
1 Year |
