Goulds Pumps 3SDX12J2GC , 3" Non-Clog Sewage Pump, Explosion Proof (5 HP, 3 Phase, 200 Volts, 7.62" Impeller Dia.)

Goulds Pumps 3SDX12J2GC , 3" Non-Clog Sewage Pump, Explosion Proof (5 HP, 3 Phase, 200 Volts, 7.62" Impeller Dia.)

👁️ [COUNT] People are currently viewing this product.

3SDX12J2GC

$10,759.80 USD
$17,933.00 USD $10,759.80 USD
Sale Sold out
Shipping calculated at checkout.

View Price in Cart

Don't see the price?

If you are unable to find the price for this item on our page, please contact us directly for a quote.

Some products require you to ADD TO CART to see the price.

Tax

NY, NJ and CT will be charged tax on most orders.

* If you are tax exempt, email your tax form to Sales@kgpowersystems.com

3SDX12J2GC Goulds 3" Non-Clog Sewage Pump, Explosion Proof (5 HP, 3 Phase, 200 Volts, 7.62" Impeller Dia.)
Applications
Hazardous commercial and industrial applications, Sewage Systems, Flood and pollution control, Dewatering and effluent, Hospitals, trailer courts, hotels and motels
Features
Cast Iron, ASTM A48, Class 30, two vane, semi-open impeller with non-clog design and pump out vanes for mechanical seal protection
Heavy duty gray cast iron, ASTM A48, Class 30, Volute type casing with 3? 125# flanged, horizontal discharge conforming to ANSI standards
Tandem mechanical seal system in an oil filled seal chamber. Each seal operates independently to ensure fail safe performance
Explosion Proof Motor for use in hazardous locations. Rated Class 1, Groups C&D

Specifications

Brand
Goulds
Catalog Number
3SDX12J2GC
Pump Type
3" Sewage Pump, Explosion Proof
Series
3SDX Sewage Pump
HP
5
Phase
3
Volts
200
RPM
1750
Impeller Dia.
7.62"
Impeller Code
G
Discharge Size (in.)
3"
S.F. Amps
18.3
Service Factor
1.15
Full Load Amps
17
Locked Rotor Amps
92.1
Power Cable
12/4
Power Cable Dia. (in.)
0.66
Sensor Cable Dia. (in.)
0.495
Weight (lbs.)
270
Warranty
1 Year
Notes & Pump Curve
See Support Notes
