ARB2024SL Century Belt Drive and Blower Motor, Split Phase (1/4 HP, 48Y Frame, 1725 RPM)

ARB2024SL Century Belt Drive and Blower Motor, Split Phase (1/4 HP, 48Y Frame, 1725 RPM)

👁️ [COUNT] People are currently viewing this product.

ARB2024SL

$0.00 USD
$0.00 USD
Sale Sold out
Shipping calculated at checkout.

Don't see the price?

If you are unable to find the price for this item on our page, please contact us directly for a quote.

Some products require you to ADD TO CART to see the price.

Tax

NY, NJ and CT will be charged tax on most orders.

Sales tax will need to be collected on all AMT and Jorc products, regardless of the destination state.

* If you are tax exempt and would like to place an order, email your tax exempt form to Sales@kgpowersystems.com.

** Taxes may be applied after an order is placed.

Model Number: ARB2024SL, HP: 1/4, RPM: 1725, Volts: 115/208-230, Frame: 48Y, Enclosure: TEAO, Type: Split Phase Resilient Base Motor,

Applications
Belt Drive Fans and Blowers, HVAC
Features
Class B Ins. (Class A see notes); Reversible; Continuous Duty; Sleeve & Ball Bearing; Energy Efficient $ (see notes); 60 HZ; Open and Encloseds

Tech Specs.

Brand
A.O. Smith
Model Number
ARB2024SL
HP
1/4
RPM
1725
Volts
115/208-230
Full Load Amps
4.2/2.1-2.1
Service Factor
1
Frame
48Y
Enclosure
TEAO
Apx. Wt. (lb)
20
Phase
Split Phase
Protector
None
Type
Split Phase Resilient Base Motor
Aprox "C"
9.5
Dim "AG"
7.9
Motor Mount
Resilient Base
ARB2024SL

Support Documents (pdf)

Product Literature
